Structural features of 10kV Flat contact
WCD series indoor vertical rotating isolation movable contact, is isolating moving contact of a three-phase (single-phase) 50Hz in-door rotary breakers, load isolation switch, which can be used as isolation and grounding purposed for vertical rotating / removing indoor AC metal-enclosed switchgear device.
It has a total of three common specifications, rated currents of 630A, 1250A, 1600A. And can be grouped together to become 2500A by two 1250As, and two 1600As combined to 3150A.
Model of 10kV Flat contact
Drawing
10kV Flat contact installation diagram
