17.5KV Removable AC Metal-clad Enclosed Switchgear
General
GPN1-17.5kV removable AC metal-clad switchgear (short for panel as below) is specially designed and developed by us, based on the introduction of advanced foreign design and manufacturing technology.
Applied standards
It accords with IEC298, IEC 694, DIN. VDE, GB 3906 and so on. It has perfect and reliable prevention function against misoperation.
Conditions of use
Ambient temperature: upper limit +45°C, lower limit -25°C
The altitude does not exceed 1000m (Standard); can up to 4500m for special ordering;
Atmospheric environment: the surrounding air is not seriously polluted by corrosive or flammable gases and dust
Daily average value of relative humidity: ≤ 95%. Monthly average value of relative humidity: ≤ 90%
Earthquake intensity:≤8 degree
Product features
The panel applies to 13.8kV~17.5kV 3 phase AC 50/60Hz network for receiving and distributing power energy and also for control, monitor and protection.
